Low Maintenance, Durable Construction, Easy Installation
Low cost of ownership
Description
Built Tough. Configured Simply.
The Ranger One™ LTRP-1 is a versatile ultrasonic level transmitter designed to replace conventional level sensors, proximity sensors, and proximity switches in a single compact unit. With a maximum range of 14 feet (4.3 meters) and an optimum range of 4 inches to 10 feet, it delivers reliable non-contact distance measurement across an exceptional variety of applications — liquid tanks, dry solids, factory automation, and heavy equipment monitoring.
Housed in rugged 316 stainless steel with sealed epoxy potting, the Ranger One™ is fully submersible (NEMA-4X, NEMA-6P, IP68) and built to withstand wet, dirty, and electrically noisy environments. Its unique ultrasonic signal processing is unaffected by target colour, transparency, or optical properties, making it suitable for virtually any industrial target material.
Configuration is fast and flexible: use the onboard Teach button for push-button calibration, or connect to a Windows PC via the Ranger software for full parameter control, data logging, strip chart analysis, and rapid sensor cloning. All settings are stored in non-volatile memory.
specifications
Thermal mass flow measurement without compromise
-
Performance
Maximum Range 14 feet (4.3 meters)
Optimum Range 4 inches – 10 feet (102 mm – 3 m)
Accuracy Better than 0.5% of target distance (stable air)
Repeatability ±0.03 in. (0.76 mm) or nominal 0.2% of range @ constant temp
Update Rate 20 Hz (50 ms), software adjustable
Resolution Digital: 0.0034 in. (0.086 mm); Analog: 4099 steps (0–10 VDC), 3279 steps (4–20 mA)
-
Physical
Housing Material Type 316 stainless steel
Process Connection 30 x 1.5mm Thread (1.0" MNPT)
Encapsulation Sealed epoxy potting
Protection NEMA-4X, NEMA-6P, IP68
Transducer Ruggedized piezoelectric
Cable UV resistant, potted-in, 6.5 ft (2m) standard
Weight 10.40 oz (0.29 kg)
-
Electrical
Power Input 10–30 VDC @ 60 mA max (typical 45 mA @ 24 VDC)
Temperature -40° to 158°F (-40° to 70°C)
Humidity 0–100% operating
Voltage Output 0–10 VDC or 0–5 VDC (PC customisable), 10 mA max
Current Loop 4–20 mA, current sourcing, max loop 450Ω
Sinking Switch 150 mA max @ 40 VDC max
Sourcing Switch 150 mA max @ input voltage
Serial Interface RS-232 / RS-485, Modbus protocol, 9600–115200 baud
SYNC Feature Up to 32 sensors in close proximity
Adjustment Button "Teach" or software
Configuration Stored in non-volatile memory
-
Pressure Ratings
LTRP-1-232 RS-232 Serial Interface (PC COM Port)
LTRP-1-485 RS-485 Serial Interface (multi-sensor networks)
LTRP-1-00S Switch output (NPN/PNP)
LTRP-1-00A Analog output (current/voltage)
Certifications
Thermal mass flow measurement without compromise
-
Five-Year Warranty
FLO-CORP's industry-leading warranty. The only manufacturer to offer this guarantee on all products.
-
Pre-Calibrated
Every unit is factory calibrated and verified for your specified application before shipment.
-
NPT Compliant
We don’t patch problems. We solve them at the root and build systems that fuel real, repeatable growth.
-
Quality Verified
Tested and verified by FLO-CORP's engineering team to operate as specified from day one.
-
Multi-Unit Output
Available in five different signal units to ensure best resolution for your application.
-
Calibration Available
FLO-CORP offers professional re-calibration services to maintain accuracy throughout the product's service life.
Similar products
Built for the toughest environments
-
Tracer 1000™ 3G Guided Wave Radar
Level Transmitter
RS485 communication to field devices with cellular transmission to the CONNEX 3D™ cloud portal.
-
CONNEX 3D™ Wireless Cellular Monitor
Wireless Monitor
RS485 communication to field devices with cellular transmission to the CONNEX 3D™ cloud portal.
-
Ranger Elite™ LTRE Ultrasonic Transmitter
