Product Information
The FLO-CORP Ranger One™ LTRP-1 Ultrasonic Level Transmitter is the ideal solution for position or distance measurement in factory automation settings like web control or heavy equipment. Precision remote monitoring for liquid and solid tank applications, from corn flakes to sawdust.
Part Number: LTRP-1
The Ranger One™ ultrasonic level transmitter has a maximum range of 14 feet (4.3 meters). Like all Ranger sensors, it’s built for durability and ease of use in tough industrial environments. The Ranger One™ is unique in the Ranger family of products because it can be applied to any liquid tank level application and much more. The Ranger One™ is an ideal solution for position or distance measurement in factory automation like web control or heavy equipment monitoring as well as solids level remote monitoring on anything from corn flakes to sawdust. It’s fully submersible, corrosion resistant, shock resistant ultrasonic sensors are housed in 316 stainless steel and all around tough. The Ranger One™ sensors contain a rugged transducer potted in a stainless steel housing for long life. Outputs respond to measured distance and non-contact technology means nothing touches your materials. It’s also fully configurable with our software. Ranger One includes our famous “Teach” feature for push button configuration. You can quickly adjust, optimize, save and clone your applications without calibration. The Ranger One™ has Multi-Sensor network capabilities using the Smart Communications via Modbus protocol, RS-485. The Ranger One™ would typically replace conventional ultrasonic level sensors PLUS proximity sensors and proximity switches. A proximity sensor is a sensor able to detect the presence of nearby objects without any physical contact. The Ranger One’s Unique Ultrasonic Signal Processing is impervious to most sensing targets and can be used in almost every industrial application without regard to the target material. This compact sensor is used around the world on remote liquid level systems, heavy equipment, factory automation applications and more.
BENEFITS
Maximum Accuracy: Specifically calibrated for customer’s application
Durable: Rugged stainless steel enclosure
Reliable: Non-contacting sensor for trouble-free operation
Saves Money: Low cost of ownership
Highly Adaptable: Selection of multiple outputs available
Warranty: Five-year warranty available
Specification Summary
Active Measuring Range: 0.3″ – 168″
Measurement: Liquids or Solids
Accuracy: Better than 0.5% of target distance in stable, homogeneous air environment
Process Connection: 30 x 1.5mm Thread
Compatible Products
DCX2 Digital Process Meter // CD3D Flexible Process Meter // DXM1 Relay Expansion Module
| Technology | Ultrasonic |
|---|---|
| Medium | Liquids & Solids |
| Product Type | Transmitters |
| Industries | Aerospace, Agriculture, Government Agencies, Iron, Steel & Metal, Life Sciences, Minerals & Mining, Original Equipment Manufacturers, Power & Energy, Pulp & Paper, Refined Products, Renewable Energy |
| Part Number | LTRP-1, LTRP-1-485 |
